ALL-IN-ONE INTEGRATION

Includes PCS for AC output, eliminating the need for separate power conversion equipment.

HIGH SAFETY

UL9540A compliant; LFP battery cells with advanced liquid-cooling thermal control.

HIGH ENERGY EFFICIENCY

>95% DC round-trip efficiency.

RELIABLE DESIGN

Isolated battery/electrical compartments; active ventilation; comprehensive fire safety.

LONG LIFESPAN

15-year design life; up to 30% longer battery life.

FLEXIBLE DEPLOYMENT

Easy installation, scalable design; supports third-party SCADA and cloud-based EMS.

USAGE SCENARIO

Off-grid PV, energy storage, diesel generation, and charging post

The NH1000K0.5C-1.86 is a fully integrated 0.5C-rated energy storage solution, combining PACK, PCS, EMS, BMS, HVAC, and a fire safety system in a single 20ft liquid-cooled container. Compared with air cooling, liquid cooling enables higher power density, maintains cell temperature differences within ≤4°C, and significantly extends battery lifespan while improving round-trip efficiency. Ideal for power generation, grid-side, and C&I applications requiring both high power and large capacity.

TECHNICAL SPECIFICATION

DC Side

Cell Type	LFP280Ah
PACK	46.592kWh/1P52S
Battery System	1863.68kWh/5P416S
Rated Voltage	1331.2Vdc
Voltage Range	1165 - 1498Vdc
Pack Ingress Rating	IP65

AC Side

Rated Power	100kW
Max. Power	110kW
THDi	≤3%
DC Ratio	≤0.5%lon
Nominal Voltage	400Vac/3P+N+PE
Power Factor	-1lagging~1leading
Nominal Frequency	50Hz/60Hz

General Data

Max. System Efficiency	90%
Charge/Discharge Rate	0.5P
DoD	95% (25±5℃)
SOC Accuracy	3%
Cycle Life	6,000 times
Switching Time	<100ms
Connectivity	Modbus TCP/RTU, CAN2.0
Ingress Rating	IP55
Cooling	Liquid cooling
Operating Temperature	-20℃ - 50℃
Humidity	5 - 90%RH (non-condensing)
Noise	≤80dB
Altitude	≤2,000m (derating above 2,000m)
Fire Safety	Novec 1230
Dimensions (WDH)	6,0582,4382,896(mm)
Weight	≤25t
Compliance	IEC62619, IEC61000, IEC62477, EN50549, UN38.3

NH1000K05C-1.86
