COMPACT DESIGN
Light footprint, easy framein stallation and field installation.
HIGH INTEGRATION
20kWh+ energy in one cabinet with DC/AC power conversion & thermal cooling.
EFFICIENT COOLING
Optimal air-duct design optimizes airflow for improved cooling with lowenergy consumption.
LONG CYCLE LIFE
Over 6,000 times cycle life, excellent performance of battery system.
FLEXIBLE EXPANSION
Modular design, simplified panel for expansion.
ULTIMATE SAFETY
Comprehensive safety protection with NOVEC1230 thermal prevent heat diffusion and spreading.
USAGE SCENARIO
Off-grid PV, energy storage, diesel generation, and charging post
TECHNICAL SPECIFICATION
DC Side
| Cell Type | LFP280Ah |
| PACK | 46.592kWh/1P52S |
| Battery System | 232.96kWh/1P260S |
| Rated Voltage | 832Vdc |
| Voltage Range | 728-936Vdc |
| Pack Ingress Rating | IP65 |
AC Side
| Rated Power | 100kW |
| Max. Power | 110kW |
| THDi | ≤3% |
| DC Ratio | <0.5%Ipn |
| Nominal Voltage | 400Vac/3P+N+PE |
| Power Factor | -1 lagging~1 leading |
| Nominal Frequency | 50Hz/60Hz |
General Data
| Max. System Efficiency | 90% |
| Charge/Discharge Rate | 0.5P |
| DoD | 95% (25±2°C) |
| SOC Accuracy | 3% |
| Cycle Life | 8,000 times |
| Switching Time | <100ms |
| Connectivity | Ethernet /RS485 |
| Ingress Rating | IP55 |
| Cooling | Active liquid cooling |
| Operating Temperature | -25°C - 55°C |
| Humidity | 5 ~ 95%RH, non - condensing |
| Noise | ≤75dB |
| Altitude | ≤2,000m (derating above 2,000m) |
| Fire Safety | Aerosol |
| Dimensions (W*D*H) | 1,050*1,350*2,400(mm) |
| Weight | 2570kg |
| Compliance | UN38.3, IEC62477, IEC61000, IEC62619, IEC63056, UL9540A, EN50549 |
